CROHMIQ blue / white 1000kg anti static bulk bags for dangerous chemical powders
Description:
1. TYPE D big bags with electrostatic dissipative fibres can facilitate electrostatic charge
dissipation into surroundings via corona discharge.
2. It safely dissipates static charge without the need for a ground/earth connection.
3. The breakdown voltage is not exceeding 4 KV. Type D FIBC can be used in the
presence of combustible dusts and in the presence of flammable gases or vapours.
4. This type of bags are made with CROHMIQ. Fabric is supplied by LINQ in USA.
Sinopack produces dissipative bags with anti-static coating and charge to be dissipated
via corona-effect.
5. Type D bags are suitable for packing different kinds of products which needs to be
packed in Conductive bags. No grounding is necessary for this type of bag which is a specific
advantage.
Photos:
Specifications:
| Shape | U-panel / Four-panel conductive bag |
| Capacity | 2200LBS |
| Safety factor | 5:1 |
| Base size | 39*39’’, 41*41’’ |
| Height | As per request |
| Color | White, CROHMIQ |
| Material | 100% virgin polypropylene, 5OZ to 7OZ Conductive fabric, CROHMIQ fabric Coated, Uncoated with PE liner |
| Top type | with filling spout: 14’’(D)*18’’, |
| Bottom type | discharge spout: 14’’(D)*18’’ with star petal or iris spout |
| Lifting loops | width: 2’’ / 3’’ 10’’ high side-seam loops
color: white/yellow |
| Liner | PE conductive liner, White, pink, black |
| Perimeter belt | Width: 1.2’’, 2’’, 3’’ |
| UV stabilized | 1% UV to 3% treated |
| Document pouch | PE ziplock, Envelope type |
| Label | Dissipative Bag TYPE D instruction label, Others as per request |
| Printing | Four colors at most in one side |
| Stitching | Plain stitching, chain stitching, overlock stitching |
| Packing | Packed on pallets, 20pallets/20'FCL, 44pallets/40'FCL |
| Lead time | 25days for 1 x 20'FCL; 45days for 1 x 40'FCL |
Advantage:
1. CROHMIQ is the world's safest static protective Type D FIBC
2. CROHMIQ is internationally recognized as the genuine Type D static protective bulk bag
packaging technology. The proven safety record of CROHMIQ ungrounded antistatic bulk
bags is unmatched.
3. Over 20 million CROHMIQ FIBC have been safely used, including extensive use in hazardous
flammable environments.
4. Only CROHMIQ's patented antistatic FIBC technology provides a level of safety equal to a
properly earthed conductive Type C FIBC, but without the risks of human error. For these
reasons, leading global companies have converted from Type B bulk bags and Type C bulk
bags to the optimum safety of CROHMIQ FIBC.
5. Over 3 million CROHMIQ FIBC have been safely reused after wet or dry refurbishing. The
antistatic properties of CROHMIQ Type D FIBC are permanent; therefore, its static dissipative performance does not decay with time nor wash off during wet reconditioning processes as
happens with inferior Type D FIBC.
6. Grounding CROHMIQ FIBC is not required, but CROHMIQ can be safely grounded for
applications that demand groundable bulk bags. CROHMIQ antistatic FIBC fabric is FDA and
EU food contact compliant, including 21 CFR 177.1520.
7. CROHMIQ FIBC are continuously tested in a worldclass testing laboratory for Type D bulk bags
and other antistatic and conductive bulk bags.
8. Over 15 years of thorough testing by the world's leading test laboratories has proven the safety
of CROHMIQ Type D FIBC technology. CROHMIQ complies with all the latest National and
International safety standards for static protective FIBC. Worldwide technical support by
electrostatic experts is available to all users of CROHMIQ FIBC.
CROHMIQ FIBC PROVIDE SUPERIOR ELECTROSTATIC SAFETY COMPARED TO TYPE B AND
TYPE C FIBC.
